product details

Origin:China

Brand:JNBAN

Application

Products Description

Equipment advantages:

●Intelligent: PLC control extraction and separation pressure and temperature and other parameters, operating interface is intuitive and convenient;
● High pressure: The design pressure of the extractor is 55 MPa, and the working pressure is 50 MPa;
● Safety: With hardware security protection measures, and software system has the function when overpressure the pump will be stopped ;
● Convenience: Extractor clamp quick-opening structure, and use an electric hoist to lift seal plug and loading barrel;
● Energy conservation: CO2 can be recycled, and the CO2 in the extractor and cylinder can be recover lower than 0.8 MPa;
● High efficiency: Optimize extraction process, the capacity can be increased more than 50 %.

Accessories:

The tank is equipped with CIP cleaning automatic rotating spray ball, temperature gauge, pressure gauge, explosion-proof sightglass lamp, sight glass, quickopening feeding port, etc., to ensure easy operation and meet GMP standards. The inner cylinder ofthe equipment is made of 304 and 316L.

Application

Extraction Machine Range of Application:

JNBAN Multifunctional Extracting Tank suitable for engineering operations of plants,animals, such as atmospheric
pressure,pressurized water decoction, warm immersion, heat reflux, forced circulation, seepage, aromatic oil extraction andorganic solvent recovery in pharmaceutical,biological, chemical, food, beverage and other industries. It is better to use dynamicextraction or countercurrent extraction, short time and high liquid content.

Product Paramenters

Successful Project

FAQ

Q1：What Factors Affect The Quality Of Plant Extract From Plant Extraction Machine?
The quality of the plant extract may directly or indirectly be proportional to the following factors:
●Raw material; Pay specific attention to the variety of the plant because even the slightest variation could shift the extract quality.Even the particular plant variety would be affected by climatic conditions, geographical locations, cultivations, and so on.
Unluckily, finding the balance between the specific needs is quite challenging.As such, we are guaranteeing quality with the raw materials is hectic.
●Quality of the solvent; Having the best choice solvent would result in high-quality extract and vice versa.●Selected plant extraction machine; The operating principle and operation hugely determine the quality level of the extract.

So you have to pay attention to the machine specification.
It is prudent to buy from a reputable seller with years of experience and quality.

Q2:What Heat Sources can you Employ for your Vacuum Belt Dryer?
● Steam
● Hot water
● Hot oil

Q3:Purchasing process
●Consultation, test, technical scheme determination, business negotiation, contract.

Q4:How long is the guarantee period
●1 year after finishing installation and commissioning.
